The Coaster 33 hill is a 32.74ft masthead ketch designed by Alan F. Hill and built in fiberglass by Robert Ives between 1972 and 1988.
47 units have been built.
It accomodates 6 people in 2 cabins plus salon.
The Coaster 33 hill is a heavy sailboat which is under powered. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is average. There is a short water supply range.
Main features
| Model | Coaster 33 hill | ||
| Length | 32.74 ft | ||
| Beam | 10.17 ft | ||
| Draft | 4 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 61000 |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 10.94 | ||
| Ballast / displ. | 35.06 % | ||
| Displ. / length | 345.29 | ||
| Comfort ratio | 42.35 | ||
| Capsize | 1.55 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 28.51 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 17923.56 lbs | ||
| Ballast | 6283.17 lbs | ||
| Hull speed | 7.15 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Ketch | ||
| Sail area (100%) | 468.23 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 176.96 sq.ft | ||
| Sail area main | 220.23 sq.ft | ||
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 31 HP | ||
| Fuel capacity | 75 gals |
Accommodations
| Water capacity | 80 gals | ||
| Headroom | 6.10 ft | ||
| Nb of cabins | 2 | ||
| Nb of berths | 6 | ||
| Nb heads | 1 |
Builder data
| Builder | Robert Ives | ||
| Designer | Alan F. Hill | ||
| First built | 1972 | ||
| Last built | 1988 | ||
| Number built | 47 |
