The Chassiron rf is a 34.61ft masthead sloop designed by Michel Joubert and built in fiberglass by E. Richard s.a. since 1979.
The Chassiron rf is a moderate weight sailboat which is a good performer. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Chassiron rf | ||
| Length | 34.61 ft | ||
| Beam | 11.15 ft | ||
| Draft | 5.09 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 61000 |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.66 | ||
| Ballast / displ. | 36.36 % | ||
| Displ. / length | 272.88 | ||
| Comfort ratio | 25.74 | ||
| Capsize | 1.94 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 27.07 ft | ||
| Maximum draft | 5.09 ft | ||
| Displacement | 12125.41 lbs | ||
| Ballast | 4409.24 lbs | ||
| Hull speed | 6.97 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 613.54 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 28 HP | ||
| Fuel capacity | 37 gals |
Accommodations
| Water capacity | 45 gals | ||
| Headroom | 6.17 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | E. Richard s.a. | ||
| Designer | Michel Joubert | ||
| First built | 1979 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
