Catalina 309
The Catalina 309 is a 32.75ft fractional sloop designed by Gerry Douglas and built in fiberglass by Catalina Yachts since 2005.
The Catalina 309 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Catalina 309 for sale elsewhere on the web:
Main features
| Model | Catalina 309 | ||
| Length | 32.75 ft | ||
| Beam | 11.50 ft | ||
| Draft | 6.25 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.33 | ||
| Ballast / displ. | 40.82 % | ||
| Displ. / length | 235.09 | ||
| Comfort ratio | 20.64 | ||
| Capsize | 2.15 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 26.50 ft | ||
| Maximum draft | 6.25 ft | ||
| Displacement | 9800 lbs | ||
| Ballast | 4000 lbs | ||
| Hull speed | 6.90 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 523 sq.ft | ||
| Air draft | 48.25 ft | ||
| Sail area fore | 256.50 sq.ft | ||
| Sail area main | 266.41 sq.ft | ||
| I | 42.75 ft | ||
| J | 12 ft | ||
| P | 38.75 ft | ||
| E | 13.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 21 HP | ||
| Fuel capacity | 27 gals |
Accommodations
| Water capacity | 46 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Catalina Yachts | ||
| Designer | Gerry Douglas | ||
| First built | 2005 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
