The Alden 54 is a 54.08ft cutter designed by Alden and built in fiberglass by Alden Yachts (USA) between 1985 and 2002.
The Alden 54 is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is good. There is a good water supply range.
Main features
| Model | Alden 54 | ||
| Length | 54.08 ft | ||
| Beam | 14.33 ft | ||
| Draft | 5.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.75 | ||
| Ballast / displ. | 41.10 % | ||
| Displ. / length | 254.60 | ||
| Comfort ratio | 36.81 | ||
| Capsize | 1.73 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 40 ft | ||
| Maximum draft | 10.50 ft | ||
| Displacement | 36500 lbs | ||
| Ballast | 15000 lbs | ||
| Hull speed | 8.47 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 1221 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 556.85 sq.ft | ||
| Sail area main | 453.05 sq.ft | ||
| I | 60.20 ft | ||
| J | 18.50 ft | ||
| P | 53.30 ft | ||
| E | 17 ft |
Engine
| Nb engines | 1 | ||
| Total power | 75 HP | ||
| Fuel capacity | 100 gals |
Accommodations
| Water capacity | 175 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Alden Yachts (USA) | ||
| Designer | Alden | ||
| First built | 1985 | ||
| Last built | 2002 | ||
| Number built | 0 | ?? |
