Vx one design
The Vx one design is a 19.0ft fractional sloop designed by Brian Bennett and built in fiberglass since 2010.
The Vx one design is an ultralight sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Vx one design for sale elsewhere on the web:
Main features
| Model | Vx one design | ||
| Length | 19 ft | ||
| Beam | 7.17 ft | ||
| Draft | 4.33 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 49.93 | ||
| Ballast / displ. | 30 % | ||
| Displ. / length | 30.09 | ||
| Comfort ratio | 2.67 | ||
| Capsize | 3.75 |
Hull
| Hull type | Monohull lifting keel | ||
| Construction | Fiberglass | ||
| Waterline length | 18.83 ft | ||
| Maximum draft | 4.33 ft | ||
| Displacement | 450 lbs | ||
| Ballast | 135 lbs | ||
| Hull speed | 5.81 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 183 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 75.29 sq.ft | ||
| Sail area main | 108.10 sq.ft | ||
| I | 20.13 ft | ||
| J | 7.48 ft | ||
| P | 23 ft | ||
| E | 9.40 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Brian Bennett | ||
| First built | 2010 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
Other photos
