The Vineyard vixen 34 is a 34.33ft masthead sloop designed by T. M. Hale & Assoc. and built in fiberglass since 1975.
The Vineyard vixen 34 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Vineyard vixen 34 | ||
| Length | 34.33 ft | ||
| Beam | 10.50 ft | ||
| Draft | 5.17 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.46 | ||
| Ballast / displ. | 41.60 % | ||
| Displ. / length | 270.68 | ||
| Comfort ratio | 28.58 | ||
| Capsize | 1.81 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 27.42 ft | ||
| Maximum draft | 5.17 ft | ||
| Displacement | 12500 lbs | ||
| Ballast | 5200 lbs | ||
| Hull speed | 7.02 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 552 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 282.21 sq.ft | ||
| Sail area main | 262.50 sq.ft | ||
| I | 40.90 ft | ||
| J | 13.80 ft | ||
| P | 37.50 ft | ||
| E | 14 ft |
Engine
| Nb engines | 1 | ||
| Total power | 23 HP | ||
| Fuel capacity | 28 gals |
Accommodations
| Water capacity | 45 gals | ||
| Headroom | 6.25 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | T. M. Hale & Assoc. | ||
| First built | 1975 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
