Buccaneer 305
The Buccaneer 305 is a 30.0ft masthead sloop designed by William Garden and built in fiberglass by Bayliner (Buccaneer/US Yachts) since 1977.
The Buccaneer 305 is a moderate weight sailboat which is slightly under powered. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a very short water supply range.
Buccaneer 305 for sale elsewhere on the web:
Main features
| Model | Buccaneer 305 | ||
| Length | 30 ft | ||
| Beam | 10.17 ft | ||
| Draft | 4 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.99 | ||
| Ballast / displ. | 35 % | ||
| Displ. / length | 246.81 | ||
| Comfort ratio | 25.70 | ||
| Capsize | 1.89 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 26.25 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 10000 lbs | ||
| Ballast | 3500 lbs | ||
| Hull speed | 6.87 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 543 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 283.50 sq.ft | ||
| Sail area main | 178.75 sq.ft | ||
| I | 40.50 ft | ||
| J | 14 ft | ||
| P | 32.50 ft | ||
| E | 11 ft |
Engine
| Nb engines | 1 | ||
| Total power | 23 HP | ||
| Fuel capacity | 50 gals |
Accommodations
| Water capacity | 36 gals | ||
| Headroom | 6.17 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Bayliner (Buccaneer/US Yachts) | ||
| Designer | William Garden | ||
| First built | 1977 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
