Sweden yachts 70
The Sweden yachts 70 is a 69.72ft cutter designed by Peter Norlin / Jens Östmann and built in fiberglass by Sweden Yachts between 1994 and 1997.
3 units have been built.
The Sweden yachts 70 is a moderate weight sailboat which is a good performer. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Sweden yachts 70 for sale elsewhere on the web:
Main features
| Model | Sweden yachts 70 | ||
| Length | 69.72 ft | ||
| Beam | 16.99 ft | ||
| Draft | 8.53 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.86 | ||
| Ballast / displ. | 35.48 % | ||
| Displ. / length | 210.97 | ||
| Comfort ratio | 42.15 | ||
| Capsize | 1.67 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 52.49 ft | ||
| Maximum draft | 8.53 ft | ||
| Displacement | 68343 lbs | ||
| Ballast | 24251 lbs | ||
| Hull speed | 9.71 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 2065 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 1004.50 sq.ft | ||
| Sail area main | 1060.53 sq.ft | ||
| I | 82 ft | ||
| J | 24.50 ft | ||
| P | 81.08 ft | ||
| E | 26.16 ft |
Engine
| Nb engines | 1 | ||
| Total power | 170 HP | ||
| Fuel capacity | 317 gals |
Accommodations
| Water capacity | 396 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Sweden Yachts | ||
| Designer | Peter Norlin / Jens Östmann | ||
| First built | 1994 | ||
| Last built | 1997 | ||
| Number built | 3 |
