The Seidelmann 245 is a 24.18ft fractional sloop designed by Bob Seidelmann and built in fiberglass by Seidelmann Yachts between 1981 and 1984.
The Seidelmann 245 is a light sailboat which is a high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. There is a very short water supply range.
Main features
| Model | Seidelmann 245 | ||
| Length | 24.18 ft | ||
| Beam | 8 ft | ||
| Draft | 1.92 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.59 | ||
| Ballast / displ. | 43.33 % | ||
| Displ. / length | 155.46 | ||
| Comfort ratio | 13.45 | ||
| Capsize | 2.22 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 20.50 ft | ||
| Maximum draft | 4.42 ft | ||
| Displacement | 3000 lbs | ||
| Ballast | 1300 lbs | ||
| Hull speed | 6.07 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 267 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 145.13 sq.ft | ||
| Sail area main | 121.50 sq.ft | ||
| I | 27 ft | ||
| J | 10.75 ft | ||
| P | 27 ft | ||
| E | 9 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 10 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Seidelmann Yachts | ||
| Designer | Bob Seidelmann | ||
| First built | 1981 | ||
| Last built | 1984 | ||
| Number built | 0 | ?? |
