The Olympic adventure 47 is a 47.0ft masthead ketch designed by Ted Brewer and built in fiberglass by Olympic Marine (GREECE) since 1974.
The Olympic adventure 47 is a light sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Main features
| Model | Olympic adventure 47 | ||
| Length | 47 ft | ||
| Beam | 14.25 ft | ||
| Draft | 5.92 ft | ||
| Country | Greece (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.85 | ||
| Ballast / displ. | 43.75 % | ||
| Displ. / length | 175.60 | ||
| Comfort ratio | 32.36 | ||
| Capsize | 1.80 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 43.33 ft | ||
| Maximum draft | 5.92 ft | ||
| Displacement | 32000 lbs | ||
| Ballast | 14000 lbs | ||
| Hull speed | 8.82 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Ketch | ||
| Sail area (100%) | 1057 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 454.41 sq.ft | ||
| Sail area main | 421.63 sq.ft | ||
| I | 54 ft | ||
| J | 16.83 ft | ||
| P | 47.75 ft | ||
| E | 17.66 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 200 gals |
Accommodations
| Water capacity | 400 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Olympic Marine (GREECE) | ||
| Designer | Ted Brewer | ||
| First built | 1974 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
