The Nicholson 26 is a 26.58ft masthead sloop designed by Camper & Nicholson and built in fiberglass by Halmatic Ltd. since 1968.
64 units have been built.
The Nicholson 26 is a very heavy sailboat which is under powered. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Nicholson 26 | ||
| Length | 26.58 ft | ||
| Beam | 7.75 ft | ||
| Draft | 5 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 10.25 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 573.66 | ||
| Comfort ratio | 47.25 | ||
| Capsize | 1.43 |
Hull
| Hull type | Monohull long keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 20 ft | ||
| Maximum draft | 5 ft | ||
| Displacement | 10280 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 5.99 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 302 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 10 HP | ||
| Fuel capacity | 6 gals |
Accommodations
| Water capacity | 30 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Halmatic Ltd. | ||
| Designer | Camper & Nicholson | ||
| First built | 1968 | ||
| Last built | 0 | ?? | |
| Number built | 64 |
Other photos
