Microtonner 19
The Microtonner 19 is a 18.04ft fractional sloop designed by Nestor Volker and built in fiberglass by Mariner Construções Náuticas Ltd. (BRA) since 1985.
The Microtonner 19 is a light sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
See all sailboats built by Mariner Construções Náuticas Ltd. (BRA)
Microtonner 19 for sale elsewhere on the web:
Main features
| Model | Microtonner 19 | ||
| Length | 18.04 ft | ||
| Beam | 8 ft | ||
| Draft | 3.61 ft | ||
| Country | Brasil (South America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 25.51 | ||
| Ballast / displ. | 32.73 % | ||
| Displ. / length | 115.64 | ||
| Comfort ratio | 6.86 | ||
| Capsize | 3 |
Hull
| Hull type | Monohull lifting keel | ||
| Construction | Fiberglass | ||
| Waterline length | 16.73 ft | ||
| Maximum draft | 3.61 ft | ||
| Displacement | 1213 lbs | ||
| Ballast | 397 lbs | ||
| Hull speed | 5.48 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 181 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 73.41 sq.ft | ||
| Sail area main | 107.19 sq.ft | ||
| I | 21.75 ft | ||
| J | 6.75 ft | ||
| P | 24.50 ft | ||
| E | 8.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Mariner Construções Náuticas Ltd. (BRA) | ||
| Designer | Nestor Volker | ||
| First built | 1985 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
Other photos
