The Merit 25 is a 24.5ft fractional sloop designed by Paul Yates and built in fiberglass by Merit Marine Inc. since 1978.
780 units have been built.
The Merit 25 is a light sailboat which is a high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Merit 25 | ||
| Length | 24.50 ft | ||
| Beam | 8 ft | ||
| Draft | 4 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.85 | ||
| Ballast / displ. | 36.21 % | ||
| Displ. / length | 161.83 | ||
| Comfort ratio | 13.15 | ||
| Capsize | 2.25 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 20 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 2900 lbs | ||
| Ballast | 1050 lbs | ||
| Hull speed | 5.99 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 277 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 138.86 sq.ft | ||
| Sail area main | 136.50 sq.ft | ||
| I | 28.75 ft | ||
| J | 9.66 ft | ||
| P | 28 ft | ||
| E | 9.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Merit Marine Inc. | ||
| Designer | Paul Yates | ||
| First built | 1978 | ||
| Last built | 0 | ?? | |
| Number built | 780 |
