Maple leaf 48
The Maple leaf 48 is a 47.67ft cutter designed by Stan Huntingford and built in fiberglass by Cooper Enterprises Inc. (CAN) since 1972.
The Maple leaf 48 is a moderate weight sailboat which is a reasonably good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Maple leaf 48 for sale elsewhere on the web:
Main features
| Model | Maple leaf 48 | ||
| Length | 47.67 ft | ||
| Beam | 14.67 ft | ||
| Draft | 6.50 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.15 | ||
| Ballast / displ. | 27.94 % | ||
| Displ. / length | 228.49 | ||
| Comfort ratio | 34.46 | ||
| Capsize | 1.82 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 40.50 ft | ||
| Maximum draft | 6.50 ft | ||
| Displacement | 34000 lbs | ||
| Ballast | 9500 lbs | ||
| Hull speed | 8.53 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 1120 sq.ft | ||
| Air draft | 58 ft | ||
| Sail area fore | 525 sq.ft | ||
| Sail area main | 414 sq.ft | ||
| I | 52.50 ft | ||
| J | 20 ft | ||
| P | 46 ft | ||
| E | 18 ft |
Engine
| Nb engines | 1 | ||
| Total power | 80 HP | ||
| Fuel capacity | 250 gals |
Accommodations
| Water capacity | 250 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Cooper Enterprises Inc. (CAN) | ||
| Designer | Stan Huntingford | ||
| First built | 1972 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
