The M32 marstrom 32 is a 31.82ft cat (rotating spar) designed by Goran Marström/Kare Ljung and built in carbon fiber or composite by Marstrom Composite AB since 2011.
The M32 marstrom 32 is an ultralight sailboat which is a very high performer.
Main features
| Model | M32 marstrom 32 | ||
| Length | 31.82 ft | ||
| Beam | 18.04 ft | ||
| Draft | 0.98 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 88.93 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 80.45 | ||
| Comfort ratio | 1.57 | ||
| Capsize | 7.08 |
Hull
| Hull type | Catamaran twin daggerboard | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 18.04 ft | ||
| Maximum draft | 5.41 ft | ||
| Displacement | 1058 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 5.69 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cat (rotating spar) | ||
| Sail area (100%) | 576 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Marstrom Composite AB | ||
| Designer | Goran Marström/Kare Ljung | ||
| First built | 2011 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
