Lindenberg 26
The Lindenberg 26 is a 26.0ft b&r designed by Lee Creekmore and built in fiberglass by Lindenberg Yachts since 1977.
51 units have been built.
The Lindenberg 26 is a light sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. There is a very short water supply range.
Lindenberg 26 for sale elsewhere on the web:
Main features
| Model | Lindenberg 26 | ||
| Length | 26 ft | ||
| Beam | 9.50 ft | ||
| Draft | 4.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.37 | ||
| Ballast / displ. | 48.60 % | ||
| Displ. / length | 196.30 | ||
| Comfort ratio | 17.25 | ||
| Capsize | 2.18 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 23 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 5350 lbs | ||
| Ballast | 2600 lbs | ||
| Hull speed | 6.43 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | B&R | ||
| Sail area (100%) | 312 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 186.38 sq.ft | ||
| Sail area main | 126 sq.ft | ||
| I | 35.50 ft | ||
| J | 10.50 ft | ||
| P | 28 ft | ||
| E | 9 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 12 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Lindenberg Yachts | ||
| Designer | Lee Creekmore | ||
| First built | 1977 | ||
| Last built | 0 | ?? | |
| Number built | 51 |
