Liberty 28
The Liberty 28 is a 28.0ft cutter designed by Joe Fennell and built in fiberglass since 1978.
70 units have been built.
The Liberty 28 is a heavy sailboat which is slightly under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally small. There is a short water supply range.
Liberty 28 for sale elsewhere on the web:
Main features
| Model | Liberty 28 | ||
| Length | 28 ft | ||
| Beam | 9.58 ft | ||
| Draft | 4 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.78 | ||
| Ballast / displ. | 40 % | ||
| Displ. / length | 371.97 | ||
| Comfort ratio | 35.95 | ||
| Capsize | 1.68 |
Hull
| Hull type | Monohull long keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 24.33 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 12000 lbs | ||
| Ballast | 4800 lbs | ||
| Hull speed | 6.61 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 515 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 15 HP | ||
| Fuel capacity | 30 gals |
Accommodations
| Water capacity | 54 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Joe Fennell | ||
| First built | 1978 | ||
| Last built | 0 | ?? | |
| Number built | 70 |
Other photos
