The Lagoon 35 is a 35.0ft fractional sloop designed by Morrelli and Melvin and built in fiberglass by Jeanneau (FRA) between 1995 and 1996.
11 units have been built.
The Lagoon 35 is a light sailboat which is a reasonably good performer. The fuel capacity is originally small. There is a good water supply range.
Main features
| Model | Lagoon 35 | ||
| Length | 35 ft | ||
| Beam | 15.75 ft | ||
| Draft | 3.25 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.24 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 144.52 | ||
| Comfort ratio | 15.60 | ||
| Capsize | 2.62 |
Hull
| Hull type | Catamaran Twin Keel | ||
| Construction | Fiberglass | ||
| Waterline length | 35 ft | ||
| Maximum draft | 3.25 ft | ||
| Displacement | 13880 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 7.93 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 620 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 36 gals |
Accommodations
| Water capacity | 120 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jeanneau (FRA) | ||
| Designer | Morrelli and Melvin | ||
| First built | 1995 | ||
| Last built | 1996 | ||
| Number built | 11 |
