Jubilee 40
The Jubilee 40 is a 47.24ft fractional sloop designed by Knud Reimers /Peter Norlin and built in fiberglass since 1990.
9 units have been built.
The Jubilee 40 is a light sailboat which is a high performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a fast cruiser.
Jubilee 40 for sale elsewhere on the web:
Main features
| Model | Jubilee 40 | ||
| Length | 47.24 ft | ||
| Beam | 8.86 ft | ||
| Draft | 6.56 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.80 | ||
| Ballast / displ. | 48.12 % | ||
| Displ. / length | 120.62 | ||
| Comfort ratio | 25.49 | ||
| Capsize | 1.56 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 35.10 ft | ||
| Maximum draft | 6.56 ft | ||
| Displacement | 11684 lbs | ||
| Ballast | 5622 lbs | ||
| Hull speed | 7.94 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 699 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Knud Reimers /Peter Norlin | ||
| First built | 1990 | ||
| Last built | 0 | ?? | |
| Number built | 9 |
Other photos
