The Jeanneau one design 35 is a 34.76ft fractional sloop designed by Daniel Andrieu and built in fiberglass by Jeanneau (FRA) between 1991 and 1995.
240 units have been built.
The Jeanneau one design 35 is a light sailboat which is a very high performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Jeanneau one design 35 | ||
| Length | 34.76 ft | ||
| Beam | 11.48 ft | ||
| Draft | 6.40 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 23.46 | ||
| Ballast / displ. | 34.08 % | ||
| Displ. / length | 137.66 | ||
| Comfort ratio | 15.49 | ||
| Capsize | 2.29 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 29.69 ft | ||
| Maximum draft | 6.40 ft | ||
| Displacement | 8070 lbs | ||
| Ballast | 2750 lbs | ||
| Hull speed | 7.30 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 588 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 213.19 sq.ft | ||
| Sail area main | 375.19 sq.ft | ||
| I | 39.37 ft | ||
| J | 10.83 ft | ||
| P | 43.15 ft | ||
| E | 17.39 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 14 gals |
Accommodations
| Water capacity | 14 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jeanneau (FRA) | ||
| Designer | Daniel Andrieu | ||
| First built | 1991 | ||
| Last built | 1995 | ||
| Number built | 240 |
