The Island packet 485525 is a 52.17ft cutter designed by Bob Johnson and built in fiberglass by Island Packet Yachts since 2002.
The Island packet 485525 is a moderate weight sailboat which is slightly under powered. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Main features
| Model | Island packet 485525 | ||
| Length | 52.17 ft | ||
| Beam | 15.33 ft | ||
| Draft | 5.25 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.87 | ||
| Ballast / displ. | 36.24 % | ||
| Displ. / length | 244.98 | ||
| Comfort ratio | 39.24 | ||
| Capsize | 1.74 |
Hull
| Hull type | Monohull long keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 43.17 ft | ||
| Maximum draft | 5.25 ft | ||
| Displacement | 44150 lbs | ||
| Ballast | 16000 lbs | ||
| Hull speed | 8.80 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 1234 sq.ft | ||
| Air draft | 63.50 ft | ||
| Sail area fore | 577.69 sq.ft | ||
| Sail area main | 480.19 sq.ft | ||
| I | 59.25 ft | ||
| J | 19.50 ft | ||
| P | 49.25 ft | ||
| E | 19.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 110 HP | ||
| Fuel capacity | 300 gals |
Accommodations
| Water capacity | 300 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Island Packet Yachts | ||
| Designer | Bob Johnson | ||
| First built | 2002 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
