The Hunter 19 1 is a 18.67ft fractional sloop designed by Hunter Design and built in fiberglass by Hunter Marine (USA) between 1981 and 1983.
The Hunter 19 1 is a light sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Hunter 19 1 | ||
| Length | 18.67 ft | ||
| Beam | 7.33 ft | ||
| Draft | 0.58 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.93 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 180.05 | ||
| Comfort ratio | 8.60 | ||
| Capsize | 2.72 |
Hull
| Hull type | Monohull centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 14.58 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 1250 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 5.12 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 166 sq.ft | ||
| Air draft | 26 ft | ||
| Sail area fore | 68.25 sq.ft | ||
| Sail area main | 87.47 sq.ft | ||
| I | 21 ft | ||
| J | 6.50 ft | ||
| P | 21 ft | ||
| E | 8.33 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hunter Marine (USA) | ||
| Designer | Hunter Design | ||
| First built | 1981 | ||
| Last built | 1983 | ||
| Number built | 0 | ?? |
