Hm 27
The Hm 27 is a 27.25ft masthead sloop designed by Ted Brewer/Robert Walstrom and built in fiberglass by DS Yachts (Schwill Yachts) (CAN) since 1975.
The Hm 27 is a heavy sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Hm 27 for sale elsewhere on the web:
Main features
| Model | Hm 27 | ||
| Length | 27.25 ft | ||
| Beam | 9.25 ft | ||
| Draft | 4.25 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.82 | ||
| Ballast / displ. | 40.81 % | ||
| Displ. / length | 332.41 | ||
| Comfort ratio | 25.43 | ||
| Capsize | 1.90 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 21.50 ft | ||
| Maximum draft | 4.25 ft | ||
| Displacement | 7400 lbs | ||
| Ballast | 3020 lbs | ||
| Hull speed | 6.21 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 398 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 210.94 sq.ft | ||
| Sail area main | 186.88 sq.ft | ||
| I | 37.50 ft | ||
| J | 11.25 ft | ||
| P | 32.50 ft | ||
| E | 11.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | DS Yachts (Schwill Yachts) (CAN) | ||
| Designer | Ted Brewer/Robert Walstrom | ||
| First built | 1975 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
