Helsen 22
The Helsen 22 is a 22.0ft masthead sloop designed by Johannes Helsen and built in fiberglass by Universal Marine Corp. (USA) since 1971.
The Helsen 22 is a light sailboat which is a good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Helsen 22 for sale elsewhere on the web:
Main features
| Model | Helsen 22 | ||
| Length | 22 ft | ||
| Beam | 8 ft | ||
| Draft | 1.16 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.15 | ||
| Ballast / displ. | 31.82 % | ||
| Displ. / length | 143.19 | ||
| Comfort ratio | 10.70 | ||
| Capsize | 2.46 |
Hull
| Hull type | Monohull swing keel | ||
| Construction | Fiberglass | ||
| Waterline length | 19 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 2200 lbs | ||
| Ballast | 700 lbs | ||
| Hull speed | 5.84 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 202 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 114 sq.ft | ||
| Sail area main | 88 sq.ft | ||
| I | 24 ft | ||
| J | 9.50 ft | ||
| P | 20 ft | ||
| E | 8.80 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Universal Marine Corp. (USA) | ||
| Designer | Johannes Helsen | ||
| First built | 1971 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
Other photos
