H boat
The H boat is a 27.25ft fractional sloop designed by Hans Groop and built in fiberglass by Ott Yacht (GER) since 1967.
6000 units have been built.
The H boat is a light sailboat which is a good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a day-boat.
H boat for sale elsewhere on the web:
Main features
| Model | H boat | ||
| Length | 27.25 ft | ||
| Beam | 7.17 ft | ||
| Draft | 4.33 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.54 | ||
| Ballast / displ. | 49.97 % | ||
| Displ. / length | 161.26 | ||
| Comfort ratio | 15.78 | ||
| Capsize | 1.95 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 20.67 ft | ||
| Maximum draft | 4.33 ft | ||
| Displacement | 3190 lbs | ||
| Ballast | 1594 lbs | ||
| Hull speed | 6.09 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 264 sq.ft | ||
| Air draft | 34.42 ft | ||
| Sail area fore | 97.02 sq.ft | ||
| Sail area main | 140.42 sq.ft | ||
| I | 24.50 ft | ||
| J | 7.92 ft | ||
| P | 28.54 ft | ||
| E | 9.84 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Ott Yacht (GER) | ||
| Designer | Hans Groop | ||
| First built | 1967 | ||
| Last built | 0 | ?? | |
| Number built | 6000 |
