Grampian 28
The Grampian 28 is a 28.0ft masthead sloop designed by Rolf van der Sleen and built in fiberglass by Grampian Marine since 1975.
107 units have been built.
The Grampian 28 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a very short water supply range.
Grampian 28 for sale elsewhere on the web:
Main features
| Model | Grampian 28 | ||
| Length | 28 ft | ||
| Beam | 9.50 ft | ||
| Draft | 4.83 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17 | ||
| Ballast / displ. | 44.35 % | ||
| Displ. / length | 209.46 | ||
| Comfort ratio | 20.81 | ||
| Capsize | 2 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 24.50 ft | ||
| Maximum draft | 4.83 ft | ||
| Displacement | 6900 lbs | ||
| Ballast | 3060 lbs | ||
| Hull speed | 6.63 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 384 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 219 sq.ft | ||
| Sail area main | 165.38 sq.ft | ||
| I | 36.50 ft | ||
| J | 12 ft | ||
| P | 31.50 ft | ||
| E | 10.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 20 gals |
Accommodations
| Water capacity | 20 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Grampian Marine | ||
| Designer | Rolf van der Sleen | ||
| First built | 1975 | ||
| Last built | 0 | ?? | |
| Number built | 107 |
Other photos
