Golden wave 48
The Golden wave 48 is a 47.83ft masthead sloop designed by Britton Chance and built in fiberglass by Cheoy Lee Shipyard since 1981.
The Golden wave 48 is a moderate weight sailboat which is a good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is an excellent water supply range.
Golden wave 48 for sale elsewhere on the web:
Main features
| Model | Golden wave 48 | ||
| Length | 47.83 ft | ||
| Beam | 15.92 ft | ||
| Draft | 6.50 ft | ||
| Country | Hong Kong (Asia) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.51 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 219.12 | ||
| Comfort ratio | 29.74 | ||
| Capsize | 1.99 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 40.58 ft | ||
| Maximum draft | 6.50 ft | ||
| Displacement | 32800 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 8.54 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 1244 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 697.02 sq.ft | ||
| Sail area main | 546.93 sq.ft | ||
| I | 66.70 ft | ||
| J | 20.90 ft | ||
| P | 61.80 ft | ||
| E | 17.70 ft |
Engine
| Nb engines | 1 | ||
| Total power | 80 HP | ||
| Fuel capacity | 80 gals |
Accommodations
| Water capacity | 210 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Cheoy Lee Shipyard | ||
| Designer | Britton Chance | ||
| First built | 1981 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
