Gladiator 24
The Gladiator 24 is a 24.0ft fractional sloop designed by William Lapworth and built in fiberglass by Continental Plastics Inc. (USA) since 1958.
The Gladiator 24 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a day-boat.
Gladiator 24 for sale elsewhere on the web:
Main features
| Model | Gladiator 24 | ||
| Length | 24 ft | ||
| Beam | 7.50 ft | ||
| Draft | 4 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.09 | ||
| Ballast / displ. | 53.25 % | ||
| Displ. / length | 214.84 | ||
| Comfort ratio | 19.16 | ||
| Capsize | 1.92 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 20 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 3850 lbs | ||
| Ballast | 2050 lbs | ||
| Hull speed | 5.99 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 277 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 120.38 sq.ft | ||
| Sail area main | 156.31 sq.ft | ||
| I | 26.75 ft | ||
| J | 9 ft | ||
| P | 30.50 ft | ||
| E | 10.25 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Continental Plastics Inc. (USA) | ||
| Designer | William Lapworth | ||
| First built | 1958 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
Other photos
