Freeport 36 islander
The Freeport 36 islander is a 35.75ft masthead sloop designed by Robert Perry and built in fiberglass by Islander / Tradewind Yachts between 1976 and 1984.
150 units have been built.
The Freeport 36 islander is a heavy sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is average. There is a good water supply range.
Freeport 36 islander for sale elsewhere on the web:
Main features
| Model | Freeport 36 islander | ||
| Length | 35.75 ft | ||
| Beam | 12 ft | ||
| Draft | 5.25 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.01 | ||
| Ballast / displ. | 44.29 % | ||
| Displ. / length | 364.92 | ||
| Comfort ratio | 32.02 | ||
| Capsize | 1.87 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 27.50 ft | ||
| Maximum draft | 5.25 ft | ||
| Displacement | 17000 lbs | ||
| Ballast | 7530 lbs | ||
| Hull speed | 7.03 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 659 sq.ft | ||
| Air draft | 53 ft | ||
| Sail area fore | 391.53 sq.ft | ||
| Sail area main | 267.75 sq.ft | ||
| I | 46.75 ft | ||
| J | 16.75 ft | ||
| P | 42 ft | ||
| E | 12.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 42 HP | ||
| Fuel capacity | 80 gals |
Accommodations
| Water capacity | 125 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Islander / Tradewind Yachts | ||
| Designer | Robert Perry | ||
| First built | 1976 | ||
| Last built | 1984 | ||
| Number built | 150 |
