Freedom 32
The Freedom 32 is a 32.75ft fractional sloop (free standing) designed by Gary Hoyt and built in fiberglass by Freedom Yachts between 1983 and 1986.
90 units have been built.
The Freedom 32 is a moderate weight sailboat which is a good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally small. There is a short water supply range.
Freedom 32 for sale elsewhere on the web:
Main features
| Model | Freedom 32 | ||
| Length | 32.75 ft | ||
| Beam | 12.25 ft | ||
| Draft | 4.92 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.62 | ||
| Ballast / displ. | 39.11 % | ||
| Displ. / length | 234.01 | ||
| Comfort ratio | 17.65 | ||
| Capsize | 2.36 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 25.75 ft | ||
| Maximum draft | 4.92 ft | ||
| Displacement | 8950 lbs | ||
| Ballast | 3500 lbs | ||
| Hull speed | 6.80 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop (Free standing) | ||
| Sail area (100%) | 500 sq.ft | ||
| Air draft | 49 ft | ||
| Sail area fore | 135.27 sq.ft | ||
| Sail area main | 273 sq.ft | ||
| I | 33.40 ft | ||
| J | 8.10 ft | ||
| P | 39 ft | ||
| E | 14 ft |
Engine
| Nb engines | 1 | ||
| Total power | 22 HP | ||
| Fuel capacity | 20 gals |
Accommodations
| Water capacity | 46 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Freedom Yachts | ||
| Designer | Gary Hoyt | ||
| First built | 1983 | ||
| Last built | 1986 | ||
| Number built | 90 |
