Farr 39ml
The Farr 39ml is a 39.0ft fractional sloop designed by Bruce Farr and built in fiberglass by Cookson Boats (NZ) since 1995.
The Farr 39ml is a light sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a very short water supply range.
Farr 39ml for sale elsewhere on the web:
Main features
| Model | Farr 39ml | ||
| Length | 39 ft | ||
| Beam | 12.53 ft | ||
| Draft | 8.50 ft | ||
| Country | New Zealand | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 29.17 | ||
| Ballast / displ. | 50.10 % | ||
| Displ. / length | 113.73 | ||
| Comfort ratio | 15.35 | ||
| Capsize | 2.31 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 34.30 ft | ||
| Maximum draft | 8.50 ft | ||
| Displacement | 10280 lbs | ||
| Ballast | 5150 lbs | ||
| Hull speed | 7.85 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 859 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 364.70 sq.ft | ||
| Sail area main | 493.83 sq.ft | ||
| I | 50.20 ft | ||
| J | 14.53 ft | ||
| P | 51.90 ft | ||
| E | 19.03 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 18 gals |
Accommodations
| Water capacity | 30 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Cookson Boats (NZ) | ||
| Designer | Bruce Farr | ||
| First built | 1995 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
