The Endeavor 26 lapworth is a 25.75ft fractional sloop designed by William Lapworth and built in fiberglass by Schock W.D. between 1963 and 1967.
56 units have been built.
The Endeavor 26 lapworth is a moderate weight sailboat which is a high performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Endeavor 26 lapworth | ||
| Length | 25.75 ft | ||
| Beam | 7 ft | ||
| Draft | 4 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.09 | ||
| Ballast / displ. | 50 % | ||
| Displ. / length | 244.95 | ||
| Comfort ratio | 18.21 | ||
| Capsize | 1.90 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 18 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 3200 lbs | ||
| Ballast | 1600 lbs | ||
| Hull speed | 5.69 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 272 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 116.24 sq.ft | ||
| Sail area main | 155.82 sq.ft | ||
| I | 25.83 ft | ||
| J | 9 ft | ||
| P | 28 ft | ||
| E | 11.13 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Schock W.D. | ||
| Designer | William Lapworth | ||
| First built | 1963 | ||
| Last built | 1967 | ||
| Number built | 56 |
