Elan 350
The Elan 350 is a 34.78ft fractional sloop designed by Rob Humphreys and built in fiberglass by Elan Yachts (SLO) between 2011 and 2013.
The Elan 350 is a light sailboat which is a good performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Elan 350 for sale elsewhere on the web:
Main features
| Model | Elan 350 | ||
| Length | 34.78 ft | ||
| Beam | 11.48 ft | ||
| Draft | 7.05 ft | ||
| Country | Slovenia (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.68 | ||
| Ballast / displ. | 25.88 % | ||
| Displ. / length | 144.67 | ||
| Comfort ratio | 21 | ||
| Capsize | 2.02 |
Hull
| Hull type | Monohull fin keel with bulb and dual rudders | ||
| Construction | Fiberglass | ||
| Waterline length | 33.14 ft | ||
| Maximum draft | 7.71 ft | ||
| Displacement | 11795 lbs | ||
| Ballast | 3053 lbs | ||
| Hull speed | 7.71 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 635 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 298.64 sq.ft | ||
| Sail area main | 336.15 sq.ft | ||
| I | 45.18 ft | ||
| J | 13.22 ft | ||
| P | 44.26 ft | ||
| E | 15.19 ft |
Engine
| Nb engines | 1 | ||
| Total power | 30 HP | ||
| Fuel capacity | 20 gals |
Accommodations
| Water capacity | 46 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Elan Yachts (SLO) | ||
| Designer | Rob Humphreys | ||
| First built | 2011 | ||
| Last built | 2013 | ||
| Number built | 0 | ?? |
Other photos
