Drascombe lugger
The Drascombe lugger is a 18.75ft gunter-yawl designed by John L. Watkinson and built in fiberglass by Honnor Marine Ltd. since 1968.
2000 units have been built.
The Drascombe lugger is an ultralight sailboat which is a very high performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Drascombe lugger for sale elsewhere on the web:
Main features
| Model | Drascombe lugger | ||
| Length | 18.75 ft | ||
| Beam | 6.25 ft | ||
| Draft | 0.83 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 27.48 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 87.86 | ||
| Comfort ratio | 5.11 | ||
| Capsize | 2.97 |
Hull
| Hull type | Monohull centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 14.50 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 600 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 5.10 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Gunter-Yawl | ||
| Sail area (100%) | 122 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Honnor Marine Ltd. | ||
| Designer | John L. Watkinson | ||
| First built | 1968 | ||
| Last built | 0 | ?? | |
| Number built | 2000 |
Other photos
