Diva 39
The Diva 39 is a 38.71ft fractional sloop designed by Bernt Lindquist/Peter Ståhle and built in fiberglass by Fabola Boats (SWE) between 1982 and 1989.
The Diva 39 is a light sailboat which is a high performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Diva 39 for sale elsewhere on the web:
Main features
| Model | Diva 39 | ||
| Length | 38.71 ft | ||
| Beam | 9.80 ft | ||
| Draft | 5.75 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.04 | ||
| Ballast / displ. | 46.12 % | ||
| Displ. / length | 151.57 | ||
| Comfort ratio | 22.10 | ||
| Capsize | 1.83 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 30.80 ft | ||
| Maximum draft | 5.75 ft | ||
| Displacement | 9920 lbs | ||
| Ballast | 4575 lbs | ||
| Hull speed | 7.44 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 605 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 267.07 sq.ft | ||
| Sail area main | 337.64 sq.ft | ||
| I | 41.73 ft | ||
| J | 12.80 ft | ||
| P | 45.75 ft | ||
| E | 14.76 ft |
Engine
| Nb engines | 1 | ||
| Total power | 18 HP | ||
| Fuel capacity | 10 gals |
Accommodations
| Water capacity | 22 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Fabola Boats (SWE) | ||
| Designer | Bernt Lindquist/Peter Ståhle | ||
| First built | 1982 | ||
| Last built | 1989 | ||
| Number built | 0 | ?? |
