Discoverer 18
The Discoverer 18 is a 17.58ft fractional sloop designed by Joseph V. Puccia and built in fiberglass by American Fiberglass Corp. since 1966.
The Discoverer 18 is an ultralight sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Discoverer 18 for sale elsewhere on the web:
Main features
| Model | Discoverer 18 | ||
| Length | 17.58 ft | ||
| Beam | 6.25 ft | ||
| Draft | 0.75 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 35.24 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 66.64 | ||
| Comfort ratio | 5.23 | ||
| Capsize | 2.89 |
Hull
| Hull type | Centerboard Dinghy | ||
| Construction | Fiberglass | ||
| Waterline length | 16.33 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 650 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 5.41 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 165 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | American Fiberglass Corp. | ||
| Designer | Joseph V. Puccia | ||
| First built | 1966 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
