The Diamant 3000 is a 34.09ft fractional sloop designed by Jan Kjaerulff and built in fiberglass by Ott Yacht (GER) between 1988 and 1998.
50 units have been built.
The Diamant 3000 is a light sailboat which is a very high performer. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Diamant 3000 | ||
| Length | 34.09 ft | ||
| Beam | 8.20 ft | ||
| Draft | 5.41 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 23.61 | ||
| Ballast / displ. | 32.14 % | ||
| Displ. / length | 136.49 | ||
| Comfort ratio | 19.75 | ||
| Capsize | 1.79 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 27.23 ft | ||
| Maximum draft | 5.41 ft | ||
| Displacement | 6173 lbs | ||
| Ballast | 1984 lbs | ||
| Hull speed | 6.99 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 495 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 235.83 sq.ft | ||
| Sail area main | 335.29 sq.ft | ||
| I | 39.37 ft | ||
| J | 11.98 ft | ||
| P | 45.93 ft | ||
| E | 14.60 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 8 gals |
Accommodations
| Water capacity | 3 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Ott Yacht (GER) | ||
| Designer | Jan Kjaerulff | ||
| First built | 1988 | ||
| Last built | 1998 | ||
| Number built | 50 |
