Dehler 45
The Dehler 45 is a 44.95ft fractional sloop designed by Simonis Voogd and built in fiberglass by Dehler Yachts since 2010.
The Dehler 45 is a light sailboat which is a high performer. It is stable / stiff and has a good righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is originally small. There is a short water supply range.
Dehler 45 for sale elsewhere on the web:
Main features
| Model | Dehler 45 | ||
| Length | 44.95 ft | ||
| Beam | 12.66 ft | ||
| Draft | 7.22 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.72 | ||
| Ballast / displ. | 36.39 % | ||
| Displ. / length | 156.80 | ||
| Comfort ratio | 27.41 | ||
| Capsize | 1.83 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 39.34 ft | ||
| Maximum draft | 7.22 ft | ||
| Displacement | 21385 lbs | ||
| Ballast | 7782 lbs | ||
| Hull speed | 8.40 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1042 sq.ft | ||
| Air draft | 68.40 ft | ||
| Sail area fore | 465.80 sq.ft | ||
| Sail area main | 576.04 sq.ft | ||
| I | 56.46 ft | ||
| J | 16.50 ft | ||
| P | 57.09 ft | ||
| E | 20.18 ft |
Engine
| Nb engines | 1 | ||
| Total power | 39 HP | ||
| Fuel capacity | 44 gals |
Accommodations
| Water capacity | 61 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Dehler Yachts | ||
| Designer | Simonis Voogd | ||
| First built | 2010 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
Other photos
