Dash 34
The Dash 34 is a 34.04ft fractional sloop designed by Laurie Davidson and built in fiberglass between 1981 and 1984.
The Dash 34 is an ultralight sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Dash 34 for sale elsewhere on the web:
Main features
| Model | Dash 34 | ||
| Length | 34.04 ft | ||
| Beam | 11 ft | ||
| Draft | 6.25 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 26.36 | ||
| Ballast / displ. | 47.12 % | ||
| Displ. / length | 91.16 | ||
| Comfort ratio | 10.70 | ||
| Capsize | 2.54 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 29.42 ft | ||
| Maximum draft | 6.25 ft | ||
| Displacement | 5200 lbs | ||
| Ballast | 2450 lbs | ||
| Hull speed | 7.27 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 493 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 204.13 sq.ft | ||
| Sail area main | 288.75 sq.ft | ||
| I | 35.50 ft | ||
| J | 11.50 ft | ||
| P | 38.50 ft | ||
| E | 15 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Laurie Davidson | ||
| First built | 1981 | ||
| Last built | 1984 | ||
| Number built | 0 | ?? |
Other photos
