The Corel 45 is a 45.47ft fractional sloop designed by Farr Yacht Design, Ltd. and built in fiberglass with kevlar by Carroll Marine since 1996.
The Corel 45 is a light sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Corel 45 | ||
| Length | 45.47 ft | ||
| Beam | 13.91 ft | ||
| Draft | 9.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 31.64 | ||
| Ballast / displ. | 52.51 % | ||
| Displ. / length | 105.41 | ||
| Comfort ratio | 16.99 | ||
| Capsize | 2.25 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass with kevlar | ||
| Waterline length | 40.16 ft | ||
| Maximum draft | 9.50 ft | ||
| Displacement | 15294 lbs | ||
| Ballast | 8031 lbs | ||
| Hull speed | 8.49 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1214 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 529.37 sq.ft | ||
| Sail area main | 684.36 sq.ft | ||
| I | 59.28 ft | ||
| J | 17.86 ft | ||
| P | 61.71 ft | ||
| E | 22.18 ft |
Engine
| Nb engines | 1 | ||
| Total power | 47 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Carroll Marine | ||
| Designer | Farr Yacht Design, Ltd. | ||
| First built | 1996 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
