The Carrera 290 is a 29.17ft fractional sloop designed by Håkan Södergren and built in fiberglass since 1992.
The Carrera 290 is an ultralight sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Carrera 290 | ||
| Length | 29.17 ft | ||
| Beam | 9.45 ft | ||
| Draft | 5.57 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 32.68 | ||
| Ballast / displ. | 45.08 % | ||
| Displ. / length | 67.51 | ||
| Comfort ratio | 8.29 | ||
| Capsize | 2.64 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 26.92 ft | ||
| Maximum draft | 5.57 ft | ||
| Displacement | 2950 lbs | ||
| Ballast | 1330 lbs | ||
| Hull speed | 6.95 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 419 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 186.82 sq.ft | ||
| Sail area main | 232.42 sq.ft | ||
| I | 34.50 ft | ||
| J | 10.83 ft | ||
| P | 35.43 ft | ||
| E | 13.12 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Håkan Södergren | ||
| First built | 1992 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
