The Carina is a 19.55ft masthead sloop designed by Günther Thomat and built in wood or fiberglass by Marina-Werft GmbH & Co. KG between 1962 and 1980.
1500 units have been built.
The Carina is a moderate weight sailboat which is a good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Carina | ||
| Length | 19.55 ft | ||
| Beam | 6.92 ft | ||
| Draft | 2.95 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.28 | ||
| Ballast / displ. | 28.23 % | ||
| Displ. / length | 218.26 | ||
| Comfort ratio | 13.08 | ||
| Capsize | 2.25 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Wood or fiberglass | ||
| Waterline length | 15.65 ft | ||
| Maximum draft | 2.95 ft | ||
| Displacement | 1874 lbs | ||
| Ballast | 529 lbs | ||
| Hull speed | 5.30 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 173.30 sq.ft | ||
| Air draft | 22.47 ft | ||
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Marina-Werft GmbH & Co. KG | ||
| Designer | Günther Thomat | ||
| First built | 1962 | ||
| Last built | 1980 | ||
| Number built | 1500 |
